Description
Makita HP332DZ 12V Max Li-ion CXT Cordless Brushless Hammer Driver Drill
Introducting the first Brushless Hammer Drill to the 12V Makita range, HP332DZ, featuring slide type Li-ion batteries and an ergonomic design made famous by 18V LXT tools. BL Brushless models will deliver even more power and longer runtimes in the industries NEW most compact platform.
The HP332DZ is ideal tools for kitchen fitters, second fix carpenters, electricians, plumbers and mechanics as well as all tradespeople that require a compact, powerful drill.
LED Joblight with pre-glow and after glow function, lights up the work piece making it easier to view working area
Variable speed trigger has been designed so that drill speed can be easily controlled via the trigger
CXT (Compact eXtreme Technology) ultra compact and lightweight design allows users to comfortably handle the tools for prolonged periods of time
Mechanical 2 speed provides the user with more control of the tool, allowing selection between 2 speeds
In order to provide maximum thrust to the bit, the top back of the handle is ergonomically contoured and widened to perfectly fit the U-shape between thumb and index finger
Newly designed compact high power brushless motor enables higher power and longer run times
Specifications:Voltage: 12V
No load speed:
Hi: 0-1500rpm
Lo: 0-450rpm
Impacts per minute:
Hi: 0-22,500imp
Lo: 0-6750imp
Drill chuck capacity: 0.8-10mm
Max capacity:
Masonry: 8mm
Steel: 10mm
Wood: 28mm
Max tightening torque:
Hard: 35Nm
Soft: 21Nm
Weight: 1.1kg
Makita TD111DZ 12V Max Li-ion CXT Cordless Brushless Impact Driver
High power 135Nm torque
Brushless motor
LED joblight
2 Speed impact selection
CXT - Compact Extreme Technology
Compact and lightweight design
Assist mode - When fastening screws the driver starts slowly when trigger is fully depressed, in order to stabilise the screw. Once the driver begins to impact the speed is automatically increased to maximum RPM to drive home the screw
Specifications:Voltage: 12V Max
Capacity:
Machine screw: M4 - M8
Standard bolt: M5 - M14
High strength bolt: M5 - M12
Coarse thread: 22 - 90mm
Drive: 6.35mm (1/4) Hex
Impacts per minute:
High: 0 - 3900ipm
Low: 0 - 1600ipm
No load speed:
High: 0 - 3000rpm
Low: 0 - 1300rpm
Max fastening torque: 135Nm
Length: 135mm
Weight: 0.9kg
Makita BL1021B-L 12V Max 2.0Ah Li-ion CXT Cordless Slide Battery with Gauge
The New Makita 12V Max platform has developed and introduced the slide style batteries to their sub-compact 12V tool range, unlike the cassette style batteries from previous models. The 12V Max slide batteries offer improved high-capacity, ease of use and durability like, styled like the 18V range.
The Makita 12V Max 2.0Ah Slide Battery, BL1021B-L, also features a battery fuel gauge indicator that display battery charge via four LED lights located on the back of the battery. The battery fuel gauge has been located on the back of the battery ensuring convenience for the user - being able to quickly view the battery charge from the back of the tool, without having to stop and turn the tool around.
The benefits of slide type over cassette type batteries are a more stable contact between battery and tool - multiple contact points ensure stable connection even with the tool under extreme vibration, same ergonomic design as 18V LXT products, and battery terminals are protected from shorting out when thrown into tool bags.
Using a slide battery allows the 12V Max range of tools to have a more slender, ergonomically designed handles - smaller and more comfortable than handles of cassette style batteries which have to be designed around the battery.
Unbelievable 30 minute charge time
Newly designed 12V MAX slide type battery platform
CXT - Compact eXtreme Technology
Compact and lightweight design
Battery fuel gauge indicator displays battery charge via 4 LED lights; 1 LED on is 0% to 25%, 2 LEDs on is 25% to 50%, 3 LEDs on is 50% to 75% and 4 LEDs on is 70% to 100% charged
Specifications:Voltage: 12V Max
Amp Hour: 2.0Ah
Cell type: Lithium-Ion
Charging time:
DC10SB: 30 minutes
DC10WD: 70 minutes
Makita DC10SB 12V Max Li-ion CXT Rapid Battery Charger
The Makita DC10SB has been specially designed for charging the new slide Li-ion Batteries for the Makita 12V Max CXT series. The DC10SB provides rapid charge times for the 12V MAX battery platform, being able to fully charge a 1.5Ah battery in 22 minutes. Stand-by time is greatly reduced as the DC10SB is equipped with a built in cooling fan. This fan effectively cools down ever battery cell with the forced air cooling system.
The DC18SB also includes a charging status indicator to show the charging status of the battery. This is shown in 2 stages; Less than 80% and 80% or more.
Compact and lightweight design
Forced air cooling system effectively cools down every battery cell
Charging status indicator - shows the charging status of a battery being charged in 2 stages: less than 80% and 80% or more
Multi-Contact Slide-type Terminal - Ensures stable contact with battery even under extreme movement
Specifications:Voltage: 12V Max
Charging times:
1.5Ah: 22 minutes
2.0Ah: 30 minutes
4.0Ah: 60 minutes
Makita 821549-5 Makpac Connector Carry Case System - Type 1
The Makita MAKPAC connector case system designed for the professional. Strong and collapsible carry handles make the connector cases easy to move and store. Rounded grips make it easy to remove the individual cases. The MAKPAC connector case system consists of four cases varying in height. The cases can be stacked on top of each other and locked together with the locking latches. The interconnected cases take up less storage space and are easy to transport to and from the work site.
Stackable for storage and easy transportation
Strong and collapsible handles
Four different sizes to choose from
To suit:4329
4350FCT
4351FCT
DA331DZ
DF030DW
HP1630
HP1631
HP1640
DF330DZ
HP1641
HP2051
HP2071F
HP330D
JR100D
JV100D
TD090DW
TW100D
Specifications:Type: 1
Dimensions (L x W x H): 396mm x 296mm x 105mm
Weight: 1.3kg
