Description
Includes
1 x MAKITA 18V Brushless Hammer Drill Driver Skin DHP486Z
1 x MAKITA 18V 1/4inch Brushless Impact Driver Skin DTD154Z
2 x MAKITA 18V 5.0Ah Lithium-Ion Battery BL1850BL
1 x MAKITA 18V Lithium-Ion Battery Charger DC18RC
1 x MAKITA MacPac
MAKITA 18V Brushless Hammer Drill Driver Skin DHP486Z
The 18V Brushless Hammer Driver Drill provides 141Nm of maximum fastening torque and no load speed of 2,100rpm combining rapid drilling speeds with high levels of torque. This model has been redesigned with a newly designed motor and gear ratio achieving not only more power but also increasing the performance in continuous heavy-duty applications.
Not only has the performance on this model been increased but it is also considerably shorter. At 178mm in length this model is 27mm shorter than the previous model. Making it the most compact drill in its class and extremely comfortable to use in all applications.
Compact Design for improved handling and control the overall length has been reduced by 27mm vs. the previous model
3 Drilling Modes screwdriving mode (rotation with clutch) for achieving an even consistent finish when fastening screws. Drilling mode (rotation only) achieving 141Nm max. torque. Hammer Drilling mode (rotation with hammering) on the for drilling in masonry up to a maximum 16mm hole diameter.
LED Joblight high brightness twin LED joblight with pre-glow and after glow functions. Illuminating the working area for greater visibility during application
High Power Output This model has been redesigned with a newly designed motor and gear ratio achieving not only more power but also increasing the performance in continuous heavy-duty applications.
2 Speed Mechanical Gearing high speed mode produces 2,100rpm for rapid drilling speed while low speed produces high levels of torque to suit high load operation.
All metal gear construction allow for smoothly transfer of power in high load applications. While the highly durable materials ensure this tool has unmatched durability, and will continue to perform in years to come.
XPT Extreme Protection Technology protects the tool against dust & moisture even in the harshest jobsite conditions, increasing durability
Specifications
Max. drilling capacities in wood:
Auger bit: 50mm
Self-feeding bit: 76mm
Hole saw: 152mm
Max. drilling capacities in steel: 13mm
Max. drilling capacities in masonry: 16mm
No load speed:
Hi: 0 - 2,100rpm
Lo: 0 - 550rpm
Impact rate:
Hi: 0 - 31,500ipm
Lo: 0 - 8,250ipm
Max. peak torque: 141Nm
Max. tightening torque:
Hard: 130Nm
Soft: 65Nm
MAKITA 18V 1/4inch Brushless Impact Driver Skin DTD154Z
The Makita DTD154Z Brushless Impact Driver has a high rotational speed of 3,600rpm, which is optimum for fast tightening of self-drilling screws. Featuring an aluminium hammer case, variable speed control and one-touch bit installation, this is a powerful and compact drill to suit any line of work. It also features electronic 3-stage impact power selection and the new T-Mode especially for tightening self-drilling screws.
Aluminium hammer case
One-touch bit installation, no need to pull bit sleeve for bit installation
Twin LED job light with pre-glow and afterglow functions
High rotation speed at 3600rpm
Variable speed controlled by trigger
Ergonomically designed handle with soft grip provides comfortable grip and more control while minimising hand fatigue and pain
Electronic 3-stage impact power selection - in order to reduce fault tightening, hard/medium/soft impact power can be selected to the material of workpiece or screw type simply by pushing a button
T-Mode is a special mode optimum for fast tightening of self drilling screws without damaging the screw and workpiece
Specifications
Voltage: 18V
Capacity:
Machine screw: M4 - M8
Standard bolt: M5 - M16
High strength bolt: M5 - M14
Coarse thread (length): 22mm - 125mm
Impacts per minute:
Speed 1: 0 - 3800ipm
Speed 2: 0 - 2600ipm
Speed 3: 0 - 1100ipm
No load speed:
Speed 1: 0 - 3600rpm
Speed 2: 0 - 2100rpm
Speed 3: 0 - 1100rpm
Max fastening torque: 175Nm
Vibration level: 12.5m/s²
Sound pressure level: 96dB(A)
Sound power level: 107dB(A)
Dimensions (L x W x H): 117mm x 79mm x 236mm
Weight: 1.2kg
MAKITA 18V 5.0Ah Lithium-Ion Battery BL1850BL
Integrated L.E.D. battery charge level indicator allows user to monitor battery charge
Up to 33% more run time per charge compared to BL1830
Fast 40 minute charging time
Battery delivers consistent power and run time in extreme temperatures, even in winter (-20°C)
Impact-resistant outer case and shock-absorbing inner-liner are engineered to protect the battery
Sixteen contact terminals maintain a constant connection with the tool to help prevent power loss or fluctuation, even during high-vibration applications
Battery resists self-discharge and remains ready for use even after long periods of storage
Sensitive electronics are protected with a thick gel coating, preventing damage against dust and moisture
Star protection computer controls - includes overload protection, over-discharge protection and over heat protection
The battery and tool communicate, protecting your tool and battery from overload by cutting power when put under abnormally high current draw
If the battery reaches a certain level of heat it will cut power to the tool, protecting the tool and battery from overheating
MAKITA 18V Lithium-Ion Battery Charger DC18RC
Fast charging - charges Li-Ion 3.0Ah battery in only22 minutes and Li-Ion Compact series batteries in only 15 mins
Built-in CPU - gathers information from the battery's memory chip to determine optimum charging method
Forced air cooling fan - cools the battery to minimise charging time
Digital power display identifies the condition of the battery and charging condition
