Description
When you need to make deep cuts fast our K 970 Ring is the answer. It has an exceptionally cutting depth of 270 mm, twice the amount of a traditional power cutter. It has a high cutting capacity, can make deep cuts from one side and is the quickest method for small and medium-sized cuts, as no time is lost on installing rails.
Deep cutting - Irregular deep cutting. Thanks to the peripheral drive you can cut far deeper than with a traditional power cutter. The cutting depth of 270 mm is sufficient to cut through a normal wall from one side only.
Sturdy and reliable - Less sensitive to outer conditions and fuel variations, thanks to the cylinder design and muffler with integrated heat deflector.
Long service intervals - A strong Poly-V belt combined with our maintenance-free starter DuraStarter and efficient filter-system Active Air Filtration ensures long service intervals.
Light and powerful - A light, compact and powerful machine with superior power-to-weight ratio.
Easy to start - The unique design of the carburettor, cylinder and digital ignition system, together with air purge and decompression valve ensure an easy start.
High power with less fuel - Our built-in automatic filter compensation SmartCarb maintains high power and lowers fuel consumption.
SmartCarb - Built-in automatic filter compensation maintains high power during the air filter life time.
DuraStarter - Virtually maintenance free starter, thanks to the dust-sealed starter and the durable starter cord.
Blocks, curbstones and pavers - Cutting building blocks, curbstones and garden pavers.
Floors and walls - Regular cutting in floors and walls.
Maintenance-free air filter - The only time the filter needs to be checked and changed is if you experience lack of power.
Less emissions and fuel consumption - X-Torq engine produces less emissions, lower fuel consumption and produces more power.
Anti-vibration system - Reduced vibrations in the cutter handle for more comfort and longer operation periods.
Poly-V belt - Provides better transmission of power, less frequent re-tensioning and extended service intervals.
Cast concrete - Cutting cast concrete.
Pipes - Pipe cutting.
Active Air Filtration - Two-step filtration system with centrifugal cleaning and a single paper filter increases product life and extends service intervals.
Maintenance-free starter - Dust-sealed starter, where the return spring and the pulley bearing are sealed, gives a virtually maintenance free starter. Developed with a durable starter cord.
Wet cutting kit - The water adjustment gives an efficient dust management and makes operation easier and more efficient.
Adjustment to openings - Cutting for minor adjustments to window and door openings.
Specifications:Engine:
Output power: 4.8 kW
Cylinder displacement: 93.6
Electrode gap: 0.5 mm
Cylinders: 1
Number of strokes: 2-stroke engine
Exhaust emissions (CO2 EU V): 736 g/kWh
Vibrations:
Vibrations left/front handle: 2.7 m/s
Vibrations right/rear handle: 3.4 m/s
Cutting Equipment:
Cutting depth, max: 270 mm
Blade diameter, max: 370 mm
Blade thickness, max: 5.6 mm
Peripheral speed, max: 55 m/s
Sound and Noise:
Sound power level, guaranteed (LWA): 115 dB(A)
Sound pressure level at operators ear: 104 dB(A)
*Blade sold separately.
